TSC 1

SELF-CLINCHING STANDOFFS

★ CLICK ME TO SEE HOW TO INSTALL THE CLINCHING PART - TSC1

ADVANTAGES OF CLINCHING PARTS:

  * May be installed using any parallel acting squeezing force.

  * Provide high pushout and torque-out resistance.

  * Do not require special hole preparation, such as chamfering and deburring.

  * Reverse side of metal sheet remains flush.

  * No retapping necessary after application.

  * Low installed costs.

★ STANDOFFS：

Used where it is necessary to stack or space components away from the panel.

Thru-threaded or blind types are generally standard.

★ Other sizes, material are available upon request.

E SELF-DRIVING NUT

MATERIAL AVAILABLE:
STEEL, STAINLESS STEEL AND BRASS

THE E SELF-DRIVING NUT OFFERS THE FOLLOWING ADVANTAGES:
1. INSTALL SLEEVE NUT TO ACCESS FRONT SIDE OF THE WORK PIECE &SCREW IN FROM BACK SIDE.
2. INSTALL WITHOUT ANY COMPLICATED TOOL AT ANY LOCATION ON THE ASSEMBLY.
3. INSTALL WITHOUT PRODUCING ANY HARMFUL MARK.
4. INSTALL INTO VARIES MATERIAL.
5. THE FANGS ON THE BODY CUT INTO THE APPLICATION DURING ASSEMBLY.
6. EASY, FAST & SAFE INSTALLATION.

AS THE SLEEVE NUT IS INSTALLED, THE FANGS ON THE BODY ACTUALLY CUT INTO THE APPLICATION & PROVIDES GRIP STRENGTH. WHEN SCREW ON THE OPPOSITE SIDE HAVE DRIVEN, THE FANGS WILL GRIP APPLICATION TIGHTLY. THE HEAD DRIVE OF SCREW CAN BE TAMPERPROOF OF CUSTOMER'S CHOICE.

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

STUD BOLT WITH NUTS

BOLT RIVET NUT

TSBS-B & TSBS-BL

MATERIALS ARE AVAILABLE FOR BOLT RIVET NUT:

STAINLESS STEEL 302/304 (A2/18-8), 316(A4/18-10), STEEL, ALUMINUM 5056/6061, BRASS C2600

CHARACTERISTCS OF BOLT (SCREW) RIVET NUT:

• BOLT (SCREW) RIVET NUT IS EASY AND FAST IN INSTALLATION WITH HANDY TOOL.
• BOLT (SCREW) RIVET NUT PROVIDES HIGH TORQUE AND STRONG THREADS IN COMPARING WITH NORMAL FASTENERS.
• WELDING PROCESS IN NOT REQUIRED IN INSTALLING BOLT (SCREW) RIVET NUT.
• BOLT (SCREW) RIVET NUT IS ABLE TO REDUCE ASSEMBLING TIME AND IMPROVE OUTPUT.
• BOLT (SCREW) RIVET NUT IS ABLE TO PROVIDE A STRONG BINDING SUPPORT ON COMBINATION APPLICATIONS.
• BOLT (SCREW) RIVET NUT WILL NOT LOOSEN FROM VIBRATING OBJECTS ONCE ITS' INSTALLED.
• BOLT (SCREW) IS ALREADY COMBINED WITH BLIND RIVET NUT BEFORE INSTALLATION, SO IT IS NOT NECESSARY TO INSTALL THE SCREW ON THE BLIND RIVET NUT.
• BOLT (SCREW) AND BLIND RIVET NUT IS COMBINED RIGIDLY TO SUIT VIBRATING ENVIRONMENT.
• BOLT (SCREW) RIVET NUTS ARE AVAILABLE IN BOTH UNC AND ISO DIMENSION.

★OTHER SIZES AVAILABLE:

TOP SCREW IS ABLE TO MANUFACTURE OTHER SIZES OF BOLT (SCREW) RIVET NUT APART FROM THE SIZES SHOWN IN TABLE BELOW. TOP SCREW IS ABLE TO MANUFACTURE BOLT (SCREW) RIVET NUT BASED ON THE STANDARD CYLINDRICAL, FULL HEXAGONAL AND HALF HEXAGONAL BLIND RIVET NUT IN TOP SCREW'S CATALOG. TOP SCREW IS ALSO CAPABLE FOR CUSTOMIZED SCREW (BOLT) RIVET NUT TO FULFILL YOUR REQUIREMENT FROM DESIGNING, RECOMMENDING AND OF COURSE MANUFACTURING.

NOTE 1: GRIP RANGE CAN BE AFFECTED BY PARENT MATERIAL DENSITY AND ACTUAL HOLE SIZE. WE SUGGEST TRIAL INSTALLATIONS TO DETERMINE OPTIMUM GRIP.

NOTE 2: ADDITIONAL UNF FINE THREADS, GRIP LENGTHS AND MATERIALS ARE AVAILABLE. PLEASE CONTACT TOP SCREW METAL CORP. FOR MORE DETAIL.

THREAD SPECIFICATION:

UNIFIED - 2A/21 per ASME B1.1

METRIC - 6g/21 per ASME 1.21M

BOLT RIVET NUT

MATERIALS ARE AVAILABLE FOR BOLT RIVET NUT:

STAINLESS STEEL 302/304 (A2/18-8), 316(A4/18-10), STEEL, ALUMINUM 5056/6061, BRASS C2600

CHARACTERISTCS OF BOLT (SCREW) RIVET NUT:
1. BOLT (SCREW) RIVET NUT IS EASY AND FAST IN INSTALLATION WITH HANDY TOOL.
2. BOLT (SCREW) RIVET NUT PROVIDES HIGH TORQUE AND STRONG THREADS IN COMPARING WITH NORMAL FASTENERS.
3. WELDING PROCESS IN NOT REQUIRED IN INSTALLING BOLT (SCREW) RIVET NUT.
4. BOLT (SCREW) RIVET NUT IS ABLE TO REDUCE ASSEMBLING TIME AND IMPROVE OUTPUT.
5. BOLT (SCREW) RIVET NUT IS ABLE TO PROVIDE A STRONG BINDING SUPPORT ON COMBINATION APPLICATIONS.
6. BOLT (SCREW) RIVET NUT WILL NOT LOOSEN FROM VIBRATING OBJECTS ONCE ITS' INSTALLED.
7. BOLT (SCREW) IS ALREADY COMBINED WITH BLIND RIVET NUT BEFORE INSTALLATION, SO IT IS NOT NECESSARY TO INSTALL THE SCREW ON THE BLIND RIVET NUT.
8. BOLT (SCREW) AND BLIND RIVET NUT IS COMBINED RIGIDLY TO SUIT VIBRATING ENVIRONMENT.
9. BOLT (SCREW) RIVET NUTS ARE AVAILABLE IN BOTH UNC AND ISO DIMENSION.

★OTHER SIZES AVAILABLE:

TOP SCREW IS ABLE TO MANUFACTURE OTHER SIZES OF BOLT (SCREW) RIVET NUT APART FROM THE SIZES SHOWN IN TABLE BELOW. TOP SCREW IS ABLE TO MANUFACTURE BOLT (SCREW) RIVET NUT BASED ON THE STANDARD CYLINDRICAL, FULL HEXAGONAL AND HALF HEXAGONAL BLIND RIVET NUT IN TOP SCREW'S CATALOG. TOP SCREW IS ALSO CAPABLE FOR CUSTOMIZED SCREW (BOLT) RIVET NUT TO FULFILL YOUR REQUIREMENT FROM DESIGNING, RECOMMENDING AND OF COURSE MANUFACTURING.

NOTE 1: GRIP RANGE CAN BE AFFECTED BY PARENT MATERIAL DENSITY AND ACTUAL HOLE SIZE. WE SUGGEST TRIAL INSTALLATIONS TO DETERMINE OPTIMUM GRIP.

NOTE 2: ADDITIONAL UNF FINE THREADS, GRIP LENGTHS AND MATERIALS ARE AVAILABLE. PLEASE CONTACT TOP SCREW METAL CORP. FOR MORE DETAIL.

THREAD SPECIFICATION: Unified - 2A/21 per ASME B1.1

                                              Metric ­– 6g/21 per ASME 1.21M

★CLICK ME TO SEE HOW TO INSTALL THE BOLT RIVET NUT

EXPANSION ANCHOR

UNDERCUT ANCHOR

FEATURES OF ANCHOR BOLT:

   ★ EASY TO INSTALL

   ★ HIGH LOAD CAPACITIES EVEN IN THE LOW DENSITY BASE MATERIAL

   ★ WITHOUT THERMAL BRIDGE

   ★ QUICK INSTALLATION

   ★ DOUBLE SAFETY FEATURES

   ★ MATERIAL ELECTROPLATED AND GALVANIZED

ADVANCED CURTAIN WALL SYSTEM; A.C.T.

INSTALLATION :

ADVANTAGE & BENEFIT OF ANCHOR BOLT:

   ★ INVISIBLE FROM FRONT OF FAÇADE

   ★ STRESS-FREE FIXING IN NATURAL STONE

   ★ MAXIMU POSSIBLE PULL-OUT LOEAD HIGH COLLAPSE LOADS THAN TRADITIONAL SYSTEM

   ★ FAST & EASY INSTALLATION OF REVEAL

   ★ STATIC OPTIMISED POSITION OF ANCHOR THE MAX. BENDING STRESS IS REDUCED BY 50%

FIELDS OF APPLICATION:

   ★ CURTAIN WALL INSTALLATION

   ★ BUILDING CURTAIN GLASS INSTALLATION

   ★ MARBLE INSTALLATION

   ★ STRENGTHENED GLASS INSTALLATION

E SELF-DRIVING NUT

MATERIAL AVALIABLE:

STEEL, STAINLESS STEEL AND BRASS

ADVANTAGES:

• INSTALL SLEEVE NUT TO ACCESS FRONT SIDE OF THE WORK PIECE & SCREW IN FROM BACK SIDE.

• INSTALL WITHOUT ANY COMPLICATED TOOL AT ANY LOCATION ON THE ASSEMBLY.

• INSTALL WITHOUT PRODUCING ANY HARMFUL MARK.

• INSTALL INTO VARIES MATERIAL.

• THE FANGS ON THE BODY CUT INTO THE APPLICATION DURING ASSEMBLY.

• EASY, FAST & SAFE INSTALLATION.

INSTRUCTIONS OF E-SELF DRIVING NUT:

AS THE SLEEVE NUT IS STALLED, THE FANGS ON THE BODY ACTUALLY CUT INTO THE APPLICATION & PROVIDES GRIP STRENGTH. WHEN SCREW ON THE OPPOSITE SIDE HAVE DRIVEN, THE FANGS WILL GRIP APPLICATION TIGHTLY.

FEATURE OF E-SELF DRIVING NUT

(COMPARE WITH SEX BOLTS)

1.    ROUND BODY WITH FANGS ON IT

• GRIP THE APPLICATION TIGHTLY
• CANNOT BE DISASSEMBLED EASILY
• PREVENT ANY ONE WHO INTENT TO PULL OUT

2.    SCREW HEAD CAN BE YOUR CHOICE

• THE SCREW HEAD CAN BE TAMPERPROOF
• HARDLY TO DISASSEMBLED
• COMBINE WITH GOOD SURFACE OUTLOOK

DOUBLE EFFECT OF ANTI-THEFT

YOUR BEST CHOICE

非常感謝俄羅斯客戶的來訪

THANKS FOR RUSSIAN CLIENT'S COMING.

AIR PULL SETTER

★ LG-801、LG-802、LG-803、LG-804 can choose one pulling nut.

    LG-807 without pulling nut.

CHARACTERISTICS OF AIR PULL SETTER：

1. Small size

2. Long life

3. Large working torque

4. Low energy consumption

5. Easy, fast & safe installation

6. Safety; no electrical shock; no heat generated

7. Install without producing any harmful mark

8. Under an easy pneumatic operation, a high performance can be achieved efficiently.

★ CLICK ME TO SEE HOW TO INSTALL BLIND RIVET NUT BY AIR PULL SETTER

氣動拉帽槍

AIR PULL SETTER

★ LG-801、LG-802、LG-803、LG-804 可任選一槍頭；LG-807 不附槍頭。

氣動拉帽槍的用途：

適用於五金製品、塑膠製品等工業用鉚接作業；將拉帽固定於板金、管材、鐵板、木板等。

氣動拉帽槍的特色及優點：

1. 低能源消耗

2. 具強大的工作力矩

3. 尺寸小、使用壽命長

4. 安全性高、無電阻、不會產生熱能

5. 操作方便、快速，且不會破壞工件

6. 以簡易的氣動方式，達到高效能的結果

★ 點我看氣動式拉帽槍拉鉚示範影片

SPLINED RIVET NUT

MATERIAL AVAILABLE:

STEEL, STAINLESS STEEL 302( INOX A2/18-8) AND 316 ( INOX A4/18-10), BRASS, ALUMINUM 5056

SURFACE FINSIH AVAILABLE:

STEEL: CR3 WHITE/YELLOW/BLACK ZINC PLATED, CR3 ZINC NICKEL PLATED, NICKEL PLATED

STAINLESS STEEL: CLEAN OR PASSIVATED.

BRASS: CLEAN

ALUMINUM: CLEAN

CHARACTERISTICS OF SMALL FLANGE BLIND RIVET NUT

1. THE BLIND RIVET NUT HAS BEEN SPECIALLY DEVELOPED TO GIVE DESIGNERS A STRONG AND VIBRATION- PROOF STEEL THREAD IN THIN SHEET APPLICATIONS.

2. THE BLIND RIVET NUT CAN BE USED TO ASSEMBLE TWO OR MORE SHEETS OF VARIOUS MATERIALS (STEEL, ALUMINUM, WOOD, PLASTIC, ETC.) AND CAN BE FIXED BY A SCREW.

3. THE HEAD OF SMALL FLANGE BLIND RIVET NUT IS IN A COUNTERSUNK SHAPE THAT MAKES THE APPLICATION SURFACE FLAT AND SMOOTH AFTER INSTALLATION.

4. THE BLIND RIVET NUT IS FAST AND CONVENIENT IN INSTALLATION.

5. APPLICATION SURFACE FINISH WILL NOT BE DAMAGED AFTER INSTALLTION OF BLIND RIVET NUT.

THE BLIND RIVET NUT OFFERS THE FOLLOWING ADVANTAGES

1. EASY AND FAST INSTALLATION.

2. HIGH TORQUE AND STRONG THREADS ARE COMPARABLE TO NORMAL FASTENERS.

ASSEMBLY APPLICATION

1. AUTOMATIVE

2. ELECTRICAL ENGINEERING

3. SHEET METAL

4. GENERAL LIGHT FABRICATION

★ OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

★ CLICK ME TO SEE HOW TO INSTALL THE BLIND RIVET NUT
